| ACCESSORY | |
| Shock (Trunnion) | 54W × M10 × P1.0 205mm × 22W × 8mm |
| DU Bushes Internal Diameter | 12.7mm |
| Shock Travel | TV65mm |
| Fork travel | 180mm-190mm |
| Wheel Travel | 172.2mm |
| Leverage Ration | 2.65 |
| Head Set Size | φ28.6/44 | 56/φ39.8 |
| Front Wheel Size | 29" |
| Rear Wheel Size | 29" |
| Max Rear Wheel Width | 2.6" |
| Crank Length | ≤175mm |
| Each Inboard Crank to Frame Centerline Clearance | 52mm/55mm |
| BB Length | BSA 73mm |
| Seat Post | Ø31.6 |
| OLD | 148mm |
| Chainring max | 34T |
| Brake Disc | 200mm/203mm |
| Derailleur | UDH |
| S | M | L | XL | |||
|---|---|---|---|---|---|---|
| Body Height in cm | 155-165cm | 165-175cm | 175-185cm | 185-195cm | ||
| A | Reach | 448mm | 463mm | 482mm | 495mm | |
| B | Stack | 632mm | 632mm | 636mm | 636mm | |
| C | Fork Offset | 44mm | 44mm | 44mm | 44mm | |
| D | Front Center | 803mm | 818mm | 839mm | 852mm | |
| E | Fork Length | 590mm | 590mm | 590mm | 590mm | |
| F | Wheel Base | 1242mm | 1257mm | 1278mm | 1291mm | |
| G | Rear Center | 440mm | 440mm | 440mm | 440mm | |
| H | Bottom Bracket Dror | 20mm | 20mm | 20mm | 20mm | |
| I | Max Seat Post Insertion Depth | 160mm | 190mm | 220mm | 240mm | |
| J | Top Tube Horizontal Length | 585mm | 600mm | 620mm | 633mm | |
| K | Head Tube Angle | 63.5° | 63.5° | 63.5° | 63.5° | |
| L | Head Tube Length | 105mm | 105mm | 115mm | 115mm | |
| M | Actual Seat Tube Angle | 72.5° | 72.5° | 72.5° | 72.5° | |
| N | Effective Seat Tube Angle | 77.8° | 77.8° | 77.8° | 77.8° | |
| O | Seat Tube Length | 380mm | 410mm | 445mm | 470mm |
