| ACCESSORY | |
| Shock (Eye to eye) | 36W × 230mm × 22W |
| DU Bushes Internal Diameter | 12.7mm |
| Shock Travel | TV65mm |
| Fork travel | 170mm-180mm |
| Wheel Travel | 170mm |
| Leverage Ration | 2.61 |
| Head Set Size | φ28.6/44 | 56/φ39.8 |
| Front Wheel Size | 29" |
| Rear Wheel Size | 29" |
| Max Rear Wheel Width | 2.6" |
| Crank Length | ≤175mm |
| Each Inboard Crank to Frame Centerline Clearance | 55mm |
| BB Length | BSA 73mm |
| Seat Post | Ø30.9 |
| OLD | 148mm |
| Chainring max | 34T |
| Brake Disc | 200mm/203mm |
| Derailleur | UDH |
| S | M | L | XL | XXL | |||
|---|---|---|---|---|---|---|---|
| Body Height in cm | 155-165cm | 165-175cm | 175-185cm | 185-195cm | 195-205cm | ||
| A | Reach | 450mm | 465mm | 480mm | 495mm | 510mm | |
| B | Stack | 626mm | 626mm | 635mm | 635mm | 635mm | |
| C | Fork Offset | 44mm | 44mm | 44mm | 44mm | 44mm | |
| D | Front Center | 797mm | 812mm | 832mm | 847mm | 862mm | |
| E | Fork Length | 585mm | 585mm | 585mm | 585mm | 585mm | |
| F | Wheel Base | 1232mm | 1247mm | 1266mm | 1281mm | 1286mm | |
| G | Rear Center | 435mm | 435mm | 435mm | 435mm | 435mm | |
| H | Bottom Bracket Dror | 16.5mm | 16.5mm | 16.5mm | 16.5mm | 16.5mm | |
| I | Max Seat Post Insertion Depth | 200mm | 230mm | 260mm | 290mm | 300mm | |
| J | Top Tube Horizontal Length | 585mm | 600mm | 618mm | 633mm | 648mm | |
| K | Head Tube Angle | 63.5° | 63.5° | 63.5° | 63.5° | 63.5° | |
| L | Head Tube Length | 105mm | 105mm | 115mm | 115mm | 115mm | |
| M | Actual Seat Tube Angle | 72° | 72° | 72° | 72° | 72° | |
| N | Effective Seat Tube Angle | 77.8° | 77.8° | 77.8° | 77.8° | 77.8° | |
| O | Seat Tube Length | 380mm | 410mm | 445mm | 470mm | 500mm |
